GA P55AUD3 ATX 1156 P55
+ zoomez sur l'image
GA P55AUD3 ATX 1156 P55 4DR3 GL 6S2 2S3 RAID 14USB2 2USB3
| Prix : | 145.38 € |
| 121.15 € HT |
72h SUR COMMANDE
Nouveau modèle intgrant les nouvelles interfaces ultra rapides USB 3.0 et SATA3!
PRESENTATION
Format : ATX
Processeur : Intel® Core™ i7/i5 series
Socket : LGA1156
Chipset : Intel® P55 Express
Mémoire : DC 4DDR3 2200/1333/1066/800 MHz 16GB max
Slot expansion : 1PCIe x16, 1PCIe x4, 2PCIe x1, 3PCI
POINTS FORTS
- Technologie Ultra Durable 3
- Support nouvelle normes NEC Ultra rapide USB 3.0
- 3 ports USB alimentés
- Interface haute vitesse SATA3 6Gb/s
- Technologie Smart6
- Support processeur Intel Corei7/i5
- Technologie Dynamic Energy Saver 2
- Support technologie ATI CrossfireX
- Connectique Gigabit LAN
- Technologie XHD
- Technologie AutoGreen
- Technologie patented Gigabyte DualBIOS
- 8 canaux audio HD
- Compatible Windows 7
CARACTERISTIQUES TECHNIQUES
Modèle
GA-P55A-UD3
Processor
1. Support for an Intel® Core™ i7 series processor/Intel® Core™ i5 series processor in the LGA1156 package (Go to GIGABYTE's website for the latest CPU support list.)
2. L3 cache varies with CPU
Chipset
1. Intel® P55 Express Chipset
Memory
1. 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
2. Dual channel memory architecture
3. Support for DDR3 2200/1333/1066/800 MHz memory modules
4. Support for non-ECC memory modules
5. Support for Extreme Memory Profile (XMP) memory modules
* Go to GIGABYTE's website for the latest memory support list.
Audio
1. Realtek ALC888 codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for S/PDIF In/Out
5. Support for CD In
LAN
1. 1 x RTL8111D chip (10/100/1000 Mbit)
Expansion Slots
1. 1 x PCI Express x16 slot, running at x16 (PCIEX16) (The PCIEX16 slot conforms to PCI Express 2.0 standard.)
2. 1 x PCI Express x16 slot, running at x4 (PCIEX4)
3. 2 x PCI Express x1 slots
4. 3 x PCI slots
* When set Turbo SATA3 / USB3.0 (Marvell 9128 /NEC USB 3.0 Controller) to enable in BIOS setup, 1st PCIex16 slot will run at x8 bandwidth and 2nd PCIex16 slot will be disabled.
Multi-Graphics Technology
1. Support for ATI CrossFireX™ technology
Storage Interface
Chipset:
1. 6 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3, SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices
2. Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
Marvell 9128 chip:
1. 2 x SATA 6Gb/s connectors (GSATA3_6, GSATA2_7) supporting up to 2 SATA 6Gb/s devices
2. Support for SATA RAID 0
iTE IT8213 chip:
1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
iTE IT8720 chip:
1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB
Chipset:
1. Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)
NEC chip:
1. Up to 2 USB 3.0/2.0 ports on the back panel
Internal I/O Connectors
1. 1 x 24-pin ATX main power connector
2. 1 x 8-pin ATX 12V power connector
3. 1 x floppy disk drive connector
4. 1 x IDE connector
5. 6 x SATA 3Gb/s connectors
6. 2 x SATA 6Gb/s connectors
7. 1 x CPU fan header
8. 2 x system fan headers
9. 1 x power fan header
10. 1 x front panel header
11. 1 x front panel audio header
12. 1 x CD In connector
13. 1 x S/PDIF In header
14. 1 x S/PDIF Out header
15. 2 x USB 2.0/1.1 headers
16. 1 x serial port header
17. 1 x parallel port header
18. 1 x clearing CMOS jumper
Rear Panel I/O
1. 1 x PS/2 keyboard or PS/2 mouse port
2. 1 x coaxial S/PDIF Out connector
3. 1 x optical S/PDIF Out connector
4. 8 x USB 2.0/1.1 ports
5. 2 x USB 3.0 ports
6. 1 x RJ-45 port
7. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/ Side Speaker Out/Line In/Line Out/Microphone)
I/O
1. iTE IT8720 chip
H/W Monitoring
1. System voltage detection
2. CPU/System temperature detection
3. CPU/System/Power fan speed detection
4. CPU overheating warning
5. CPU/System/Power fan fail warning
6. CPU/System fan speed control
BIOS
1. 2 x 16 Mbit flash
2. Use of licensed AWARD BIOS
3. Support for DualBIOS™
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
1. Support for @BIOS
2. Support for Q-Flash
3. Support for Xpress BIOS Rescue
4. Support for Download Center
5. Support for Xpress Install
6. Support for Xpress Recovery2
7. Support for EasyTune
8. Support for Dynamic Energy Saver™ 2
9. Support for Smart 6™
10. Support for Auto Green
11. Support for eXtreme Hard Drive
12. Support for Q-Share
Bundle Software
1. Norton Internet Security (OEM version)
Operating System
1. Support for Microsoft® Windows 7/Vista/XP
Form Factor
1. ATX Form Factor; 30.5cm x 24.4cm
